3KVA–10KVA Servo Motor Automatic Voltage Stabilizer Supplier Single Phase SVC-TND Series

SVC-TND Series single-phase stabilizer (3–10KVA) features servo motor technology, maintaining 110V ±6% / 220V ±3% output, ensuring stable power and protecting sensitive home and commercial equipment.

Power: 3KVA-10KVA

Input Voltage: 80-280V AC(Ultra low voltage wide range)

Output Voltage: 110V AC/220V AC

Accuracy of Voltage Stabilization: 110V±6% 220V±3%

Description

Technical Parameters

Single-phase input voltage	160V-250V/100V-260V	Frequency	50Hz/60Hz
TND₃ Single-phase outputvoltage	0.5KVA-3KVA220V and 110V 5KVA-30KVA 220V(other voltages customization available)	Adjustable time	<1s(when input voltage has a change of 10%)
		Ambient temperature	-5℃~+40℃
		Waveform distortion	No additional waveform distortion
		Load power factor	0.8
		Dielectric strength	1500V/1min
Accuracy of voltage stabilization	220V±3%110V±6%	Insulation resistance	≥2MΩ

Model and spec
Spec(KVA)			Product size D×W×H(cm)	Package size D×W×H(cm)	Qty	Input Range
	Single-phase twowire (desk type)	SVC-3	29×22×24	59.5×36.5×28	2	160-250V
		SVC-5	46×24×19	51.5×30×25	1	160-250V
		SVC-8	57×27×24	58×33×27	1	160-250V
		SVC-10	57×27×24	58×33×27	1	160-250V
